Coil Bag Truck Tarp Wedge Style for Rolled Steel on Flatbed Trailer

  • Made of 18oz Vinyl Coated Polyester
  • Fitted design slips on quick and secures with bungee cords
  • 72 inch x 72 inch across top half of coil
  • Tapers out to 102 inch x 102" at base
  • Two rows of D-rings on all four sides
Availability: 5x6, 6x6, and 7x6 Black In Stock
Other sizes / colors ship within 5 business days
Pricing: $292.00

Customize Your Item

- -- Select Style -- -
 * required
- Select Color -
 * required


Coil Bag is a popular style of tarp used to protect rolled steel or aluminum coils while being transported on a flatbed truck and trailer. Put simply, it is one rectangular center tarp and two rounded side tarps that are sewn together creating a 3D cylinder-shaped tarp. Coil bags drastically speed up the tarping process and weigh substantially less than a lumber tarp so drivers who haul coils often typically own at least one size of coil bag.

Lookout Mountain Tarp offers three styles of coil bags each of which offers advantages. This one is known as a wedge style coil bag and many drivers prefer because it slips on after the chains have been installed and secures the same way a lumber tarp would. The wedge shape provides extra coverage around the chains eliminating the coverage gaps found with other styles of coil bags. The top half of the tarp is sewn to a shape that will fit a six foot around by six foot across coil. The lower half of the tarp tapers out matching the width of the trailer.

Regardless of which style coil bag is selected it will be constructed using our heavy duty 18oz vinyl coated polyester fabric. The fabric panels are sewn together using a double lock stitch with our black 277 polyester bonded thread. To prevent the coil's sharp edges from cutting threads the seams are inside out, sewn twice, and reinforce with webbing. D-Rings are inserted into these seams adding 14 attachment points in crucial areas. Two additional rows of D-Ring will wrap around the center of the tarp. The bottom of the tarp is folded over creating a 2-ply hem that is reinforce with webbing. #2 brass locking spur grommets are machine punched in the corners as well as about every 24" around the hem. Grommets also run up the flaps providing extra attachment points.

Coil bags are a fitted product that perform great on one specific size of coil. Attempting to use it on a smaller size can drastically reduce the tarp's life expectancy. Since coils are a round object the width and height are an identical measurement that we have shown as "Around" on the drawing. The distance from one round side to the other is shown as "Across" on the drawing. We add an extra 4" to these measurements so if you select the 6' across size it will actually measure 76". Purchase the size closest to what you will be hauling or contact us about having a custom size built.

Rolled steel coils are loaded on a flatbed one of three ways. The most common is called suicide which means the round opening is facing side to side on the trailer and if the coil was to break free it would roll towards the truck. Shotgun is the second option which means the round hole is facing front to back and the coil would roll to the side. Eye to the sky means the round hole is facing vertically. Our wedge style coil bag performs flawlessly for both the suicide and shotgun but will not fit if hauling eye to the sky.


  • CBWedge
  • CBWedge
  • Lookout Mountain Tarp
  • 5x6, 6x6, and 7x6 Black In Stock
    Other sizes / colors ship within 5 business days
  • New


Shipping Information

  • Item Requires Shipping
